PVR™ 2

Omnidirectional Measuring Microphone

Downloads

Description

Omni-directional microphone for free-field measurement. With a highly reliable circuit and a 1/4″ pre-polarized condenser capsule, it boasts high stability, low distortion and low noise in performance. Its excellent flat frequency response makes it ideal for sonic analysis systems and recording.

Features PVR 2

• Flat response, excellent electro-acoustical characteristics

• Ideal for room analysis systems, measurement, testing and recording

• Standard 1/2″ measurement diameter

• Type: Back-electret condenser mic

• Pickup Pattern: Omni-directional

• Frequency Response: 20 Hz – 20 kHz

• Sensitivity: -37 dBV/Pa (14 mV/Pa)

• Rated Impedance: 200 Ω

• Max. SPL: 132 dB

• Signal-to-noise Ratio: >70 dB

• Power Supply: 9~52V Phantom power

• Current Consumption: 2 mA

• Connector: 3-pin XLR gold-plated

Additional information

Element Type

Condenser

Pattern Type

Omni-Directional

Frequency Response

20 Hz – 20 kHz

Sensitivity

Maximum SPL

132 dB

Nominal Impedance

200 Ω

Phantom Power

Yes (9 – 52V)

Input Connectors

3-pin XLR

Color

Net Weight

5.30 oz. (150g)

Product Width

max. Ø 0.83" (21 mm)

SKU

00592790
